Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Payment Terms : T/T,L/C,Western Union,MoneyGram

Raw Material : waste newspaper, cardboard cartons, any waste paper

Delivery Time : 35 working days after get deposit payment

Finished Products : Egg Trays/Apple Trays, shoe trays, Egg Carton, Coffee cup holders tray etc.

Model Number : WY-1

Keywods : egg box tray machine

Price : USD8800

Packaging Details : in container

Machine Mould : Custermized Aluminum, ABS Plastic

Supply Ability : 10 sets per month

Egg Tray Weight : 70-75g/pcs

Worker Requirement : 2-3 workers

Feature : Semiautomatic , Automatic type

Voltage : 380V/50Hz

MOQ : 1 set

Fuel : Oil/gas/electric/diesel/as your request

Product Type : Egg Tray Machine,Egg Carton Machine

Dimensions : 3000 mm x 1500 mm x 1800 mm

Place of Origin : Jinan, Shandong, China

Brand Name : Wanyou

Power : 20kw-45KW

Contact Now

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Brief Product Intro

This low-entry semi-automatic egg tray maker adopts a streamlined single-row four-mold layout, built for small poultry farms, startup packaging workshops and family-scale production.
Unlike bulky multi-sided rotary units from other suppliers, this machine cuts extra transmission parts to lower breakdown risks and daily upkeep cost.
It runs on all kinds of waste paper as raw stock and delivers steady 1,500 egg trays per hour.
Only 1–2 workers can finish full daily operation without advanced technical skills.
The compact frame fits small workshops with limited floor space and low ceiling height. All core metal parts use thick anti-rust steel to extend service life in humid farm environments.

Unique Selling Points (Different from Peer Machines)

  1. Ultra-simplified mechanical layout, fewer moving spare parts, lower repair frequency and maintenance expense
  2. 1×4 single row mold design, lightweight aluminum molds, quick take-out without heavy disassembly
  3. Semi-auto balanced workflow: auto pulp feeding + auto vacuum forming, only simple manual tray collection
  4. Small power load, adapts unstable rural farm power grids without sudden shutdown
  5. Closed water loop design, most forming water can be reused to cut daily freshwater cost
  6. Low initial investment, can add matched drying rack or box dryer later if output grows

Core Production Steps (Short & Clear)

  1. Waste Paper Pulp Preparation

    Put waste cartons, old newspapers or used egg trays into the pulper with clean water. The machine breaks paper into even soft pulp automatically and keeps stable pulp density for forming.
  2. Vacuum Forming with 1×4 Molds

    Qualified pulp flows to the forming station. The vacuum system sucks pulp tight on four molds at once, squeezes extra water out to shape intact wet egg trays in each working cycle.
  3. Collect & Dry Finished Trays

    Workers take off wet trays from molds manually. Trays can be air-dried on racks or put into matched box dryers. Once fully dry, they are ready to hold eggs for delivery.

Technical Parameter Table


Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Box dryer 1500pcs/h drying capacity for paper egg trays, with Wood and coal fuel boiler

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour


Technical Parameters of the egg tray machine

Parameter Item Standard Data Customized Advantage for Small Farms
Hourly Output 1,500 pcs/h (30-cell standard egg tray) Stable speed, easy slow down for small batch orders
Mold Arrangement 1 row × 4 molds Light weight molds, swap within 30 minutes
Main Raw Material Waste cardboard, newspaper, recycled egg trays Cheap, easy to source locally in rural areas
Hourly Paper Consumption 110–120 kg Low material waste rate
Hourly Fresh Water Use 220–240 kg 90% wastewater recycling system included
Total Installed Power 37.5 kW Low peak power, fit rural weak power supply
Required Operators 1–2 persons Save regular labor cost
Overall Machine Size 3000 mm x 1500 mm x 1800 mm Small footprint for narrow farm workshops
Minimum Workshop Height 4 m No high-rise factory reconstruction needed
Full Machine Net Weight 2,900 kg Balanced load for ground floor simple foundation
Control Mode Simple button operation panel No complex PLC learning required
Mold Material Anti-corrosion cast aluminum Smooth tray surface, long service lifespan
Standard Warranty 12 months full machine, mold 24 months Fast spare parts supply for global buyers


Finished product by this egg tray machine

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour

Semi Automatic Paper Egg Tray Making Machine with Simple Structure and 1 by 4 Molds for Production of 1500 Pieces per Hour


Payment and delivery


Trade terms FOB Qingdao or EXW Factory
Delivery time About 35 working days after receiving the deposit.
Payment term BY T/T 40%DEPOSIT+60%BALANCE.
Time of payment When the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
Warranty time 1 year after the Egg tray machine received.
TERMS OF DELIVERY FOB Qingdao Port, China
Package In container



Suitable Application Scenarios

· Small family chicken, duck and quail poultry farms

· New packaging startups with limited startup budget

· Local egg wholesale vendors making self-use trays

· Rural waste paper recycling small workshops

· Small eco-package suppliers for neighborhood supermarkets


Welcome to contact us.

Cindy: +86 15665703348 (Whatsapp/WeChat)
